This vehicle has now been sold
TOYOTA RAV4 ESTATE
Toyota Rav4 Icon Hev 4X2 Cvt
Summary
Led Day Light Running Lights
31,000 miles
2020
Petrol/Electric Hybrid
52.3 MPG
2.5L
1 owner
Automatic
5 doors
RK70 YDX
Grey
Technical Specification
Fuel Consumption - ICE
EC Extra Urban (mpg)
50.1
EC Combined (mpg)
52.3
WLTP - MPG - Low
52.3
WLTP - MPG - Medium
60.1
WLTP - MPG - High
57.6
WLTP - MPG - Extra High
42.2
WLTP - MPG - Comb
50.4
WLTP - MPG - Low - TEL
52.3
WLTP - MPG - Low - TEH
50.2
WLTP - MPG - Medium - TEL
60.1
WLTP - MPG - Medium - TEH
58
WLTP - MPG - High - TEL
57.6
WLTP - MPG - High - TEH
54.9
WLTP - MPG - Extra High - TEL
42.2
WLTP - MPG - Extra High - TEH
40.7
WLTP - MPG - Comb - TEL
50.4
WLTP - MPG - Comb - TEH
48.8
WLTP - FC (l/100km) - Low
5.4
WLTP - FC (l/100km) - Medium
4.7
WLTP - FC (l/100km) - High
4.9
WLTP - FC (l/100km) - Extra High
6.7
WLTP - FC (l/100km) - Comb
5.6
WLTP - FC (l/100km) - Low - TEL
5.4
WLTP - FC (l/100km) - Low - TEH
5.6
WLTP - FC (l/100km) - Medium - TEL
4.7
WLTP - FC (l/100km) - Medium - TEH
4.9
WLTP - FC (l/100km) - High - TEL
4.9
WLTP - FC (l/100km) - High - TEH
5.2
WLTP - FC (l/100km) - Extra High - TEL
6.7
WLTP - FC (l/100km) - Extra High - TEH
6.9
WLTP - FC (l/100km) - Comb - TEL
5.6
WLTP - FC (l/100km) - Comb - TEH
5.8
EC Directive 1999/100/EC Applies
0
EC Urban (mpg)
53.5
Performance
Engine Torque - MKG
22.5
0 to 62 mph (secs)
8.4
Top Speed
111
Engine Power - BHP
218
Engine Power - PS
1
0 to 60 mph (secs)
0
Engine Power - KW
160
Engine Power - RPM
5700
Engine Torque - LBS.FT
163
Engine Torque - NM
221
Engine Torque - RPM
3600
General
Safety Concerns?
0
Special Edition
0
Special Order
0
Insurance Group 1 - 50 Effective January 07
25E
NCAP Adult Occupant Protection %
93
NCAP Child Occupant Protection %
87
NCAP Pedestrian Protection %
85
NCAP Safety Assist %
77
NCAP Overall Rating - Effective February 09
5
Badge Power
218
Badge Engine CC
2.5
Vehicle Homologation Class
M1
Coin Series
Icon
Coin Description
VVT-i Hybrid 2WD
Standard manufacturers warranty - Years
5
Standard manufacturers warranty - Mileage
100000
Manufacturers Paintwork Guarantee - Years
3
Man Corrosion Perforation Guarantee - Years
12
Generation Mark
5
Alternative Fuel Qualifying
1
Emissions - ICE
Noise Level dB(A)
69
CO
0.155
HC
0.017
NOx
0.003
WLTP - CO2 (g/km) - Low
123
WLTP - CO2 (g/km) - Medium
108
WLTP - CO2 (g/km) - High
111
WLTP - CO2 (g/km) - Extra High
151
WLTP - CO2 (g/km) - Comb
126
WLTP - CO2 (g/km) - Low - TEL
123
WLTP - CO2 (g/km) - Low - TEH
127
WLTP - CO2 (g/km) - Medium - TEL
107
WLTP - CO2 (g/km) - Medium - TEH
110
WLTP - CO2 (g/km) - High - TEL
111
WLTP - CO2 (g/km) - High - TEH
116
WLTP - CO2 (g/km) - Extra High - TEL
151
WLTP - CO2 (g/km) - Extra High - TEH
157
WLTP - CO2 (g/km) - Comb - TEH
131
WLTP - CO2 (g/km) - Comb - TEL
126
CO2 (g/km)
102
Standard Euro Emissions
EURO 6
Tyres
Alloys?
1
Space Saver?
0
Tyre Size Front
225/65 R17
Tyre Size Rear
225/65 R17
Tyre Size Spare
FULL SIZE
Wheel Type
17" ALLOY
Wheel Style
5-SPOKE
Engine and Drive Train
Engine Code
A25A-FXS
Cylinders - Bore (mm)
87.5
Cylinders - Stroke (mm)
103.5
CC
2487
Cylinders
4
Cylinder Layout
IN-LINE
Number of Valves
16
Camshaft
DOHC
Fuel Delivery
MULTI POINT FUEL INJECTION
Catalytic Convertor
1
Engine Layout
FRONT TRANSVERSE
Compression Ratio
14.0:1
Transmission
AUTO
Gears
1 SPEED
Weight and Capacities
Gross Vehicle Weight
2155
Fuel Tank Capacity (Litres)
55
Minimum Kerbweight
1590
Max. Towing Weight - Braked
800
Max. Towing Weight - Unbraked
750
Max. Loading Weight
565
Luggage Capacity (Seats Up)
580
No. of Seats
5
Max. Roof Load
70
Turning Circle - Kerb to Kerb
11
Vehicle Dimensions
Wheelbase
2690
Height
1685
Length
4600
Width
1855
Electric Vehicle Data
Battery Capacity in kWh
1.6
Battery Type
Nickel-Metal Hydride
Test Cycles
Emissions Test Cycle
WLTP
RDE Certification Level
RDE 2
General
The 2020 Toyota RAV4 2.5 Icon HEV4-2 CVT is part of the fifth generation RAV4 lineup (introduced in 2019). It’s built as a 5-door compact SUV with a 2.5-litre petrol-hybrid powertrain and an electronic continuously variable transmission (e-CVT). The Icon trim sits near the base of the RAV4 range, offering a good balance of standard equipment and value for money. Engine and Hybrid Powertrain Engine: 2.5 litre inline-4 petrol with Toyota’s Dynamic Force design (engine code A25A-FXS). Displacement: 2,487 cc (2.5 L). Valvetrain: 16-valve DOHC with VVT-i on intake and exhaust. Fuel System: D4S direct and port fuel injection. Hybrid System: Toyota Hybrid System combining the petrol engine with electric motor(s) and battery pack. Transmission: e-CVT automatic (electronically controlled continuously variable gear ratio). The hybrid setup means the engine works in conjunction with electric motors to maximise economy and smooth power delivery while reducing emissions compared with a pure petrol engine. Power & Performance Total System Power: Around 215 bhp (160 kW) for front-wheel-drive versions. Engine Power: 176 bhp (131 kW) @ 5,700 rpm. Engine Torque: 221 Nm @ 3,600–5,200 rpm. 0–62 mph (0–100 km/h): ,8.4 seconds (FWD). Top Speed: ,112 mph (,180 km/h). The combined output gives the RAV4 brisk acceleration for its class while maintaining a smooth, refined feel thanks to the hybrid powertrain and CVT. Fuel Economy & Emissions Under WLTP testing: Combined Fuel Economy: ,48.2–50.4 mpg (Imperial). CO2 Emissions: ,126–132 g/km. Fuel Tank Capacity: 55 litres. Toyota Media Site These figures are strong for a mid-sized SUV and help keep running costs down while also being kinder to the environment. Dimensions & Practicality Like most RAV4s of this generation: Body Style: 5-door SUV with seating for five. Boot Capacity: Spacious cargo area (typically ,580 litres VDA, depending on spec). Wheelbase: ,2,690 mm. Length/Width/Height: Approx. 4,600 mm / 1,855 mm / 1,685 mm. These dimensions make the RAV4 practical for families and everyday use while still feeling compact enough for urban driving. Equipment & Trim The Icon grade is typically the entry-level trim in the UK RAV4 range but still includes a strong basic specification: Standard Safety Kit: Toyota Safety Sense (adaptive cruise control, lane departure alert, automatic emergency braking). (Standard across RAV4 though exact features vary by year/market). Infotainment: Touchscreen with Bluetooth, USB connectivity, smartphone integration in many markets. Comfort: Air-
