2 Phase On Board Charger - 6.4kW - Home Charging Limited to 3.7kW
6m 3-Phase 16amp Type 2 - Mode 3 Charge Cable
Adjustable Steering Force
Automatic Transmission with Stop-Start and Manual Change Functions
Dynamic Chassis
Intelligent Speed Assistance
Drivers Assistance
Drive Mode Settings
Driver Alert Control
Driver Understanding System
Adaptive Cruise Control
Front and Rear Park Assist
Parking Camera 360 Surround View with Side Proximity Sensors
Road Sign Information Display
Tyre Pressure Monitoring System
Audio and Communications
Google Automotive Services
Volvo Car Connect
Volvo Car Connect Plus for 4 years - Unlimited Mobile Data (for In-car Apps and Vehicle Communication)
11.2 Centre Console Touch Screen
12V Socket - Front Tunnel Console
12v Socket - Luggage Compartment
Apple CarPlay and Android Auto - Wired
Bluetooth Handsfree System
DAB - Digital Audio Broadcasting Radio
Premium Sound by Harman Kardon
Wireless-Inductive Mobile Phone Charging
Safety and Security
Passenger Airbag Cut-Off Switch
2x Key Integrated Remote Control Central Locking with Deadlocking System and Auto Open-Close Windows
Airbags - Driver and Passenger
Anti-Theft Alarm including Immobiliser - Volume Sensor and Level Sensor
City Safety with Steering Support
Driver Assist
Driver Knee Airbag
EBA - Emergency Brake Assistance
First Aid Kit
Hill Descent Control - Off-Road Drive Mode
Hill Start Assist
IC - Inflatable Curtains - Full Length
ISOFIX Attachment - Outer Rear Seats
Keyless Drive - Keyless Entry and Keyless Start
Lane Keeping Aid
Low Speed Exterior Sound Speaker
Oncoming Lane Mitigation
Power Child Locks - Rear Doors
Power Parking Brake with Auto Hold Function
Run-Off Road Protection
Seatbelt Reminder and Pretensioners
SIPS - Side Impact Protection System
SIPS Airbags - Front Seats
Slippery Road and Hazard Light Alert
Warning Triangle
WHIPS - Whiplash Protection System - Front Seats
Exterior
Recharging Port Located in Nearside Front Wing
20in Alloy Wheels - 5 Y Spoke - Diamond Cut - Black - 255/45 Summer Tyres
Chrome Front Grille and Deco
Colour Co-Ordinated Autofolding Heated Power Door Mirrors
Dark Tinted Windows - Rear Side Windows and Rear Screen
Locking Wheel Nuts
Roof Rails - Integrated Black
Tyre Sealant Kit and Compressor
Illumination
Active Bending Headlights with Adaptive Shadow Technology
Automatic Headlight Levelling System
Automatic LED Headlights with Active High Beam incorporating Day Running Lights
Headlight Cleaning System
Home Safe and Approach Lighting
Puddle Lights
Technical Specification
Performance
Engine Torque - MKG
35.7
0 to 62 mph (secs)
5.7
Top Speed
112
Engine Power - BHP
350
Engine Power - PS
1
0 to 60 mph (secs)
0
Engine Power - KW
257
Engine Power - RPM
5500
Engine Torque - LBS.FT
258
Engine Torque - NM
350
Engine Torque - RPM
2600
General
Safety Concerns?
0
Special Edition
0
Special Order
0
Insurance Group 1 - 50 Effective January 07
40E
Service Interval Mileage
18000
Service Interval Frequency - Months
12
Badge Power
350
Badge Engine CC
2
Vehicle Homologation Class
M1
Coin Series
Plus Dark
Coin Description
T6 350 PHEV
Standard manufacturers warranty - Years
3
Standard manufacturers warranty - Mileage
60000
Manufacturers Paintwork Guarantee - Years
3
Man Corrosion Perforation Guarantee - Years
8
Alternative Fuel Qualifying
1
Tyres
Alloys?
1
Space Saver?
0
Tyre Size Front
235/55 R19
Tyre Size Rear
235/55 R19
Tyre Size Spare
TYRE REPAIR KIT
Wheel Type
19" ALLOY
Wheel Style
5 DOUBLE SPOKE
Weight and Capacities
Gross Vehicle Weight
2660
Fuel Tank Capacity (Litres)
71
Minimum Kerbweight
2093
Max. Towing Weight - Braked
2250
Max. Towing Weight - Unbraked
750
Max. Loading Weight
567
Luggage Capacity (Seats Up)
468
No. of Seats
5
Max. Roof Load
100
Luggage Capacity (Seats Down)
1395
Turning Circle - Kerb to Kerb
11.4
Electric Vehicle Data
Battery Charging Scenario 1 - Charge Time (Mins)
720
Battery Charging Scenario 1 - Power Supply - kW
2.3
Battery Charging Scenario 1 - Percentage Change
0-100
Battery Charging Scenario 2 - Charge Time (Mins)
420
Battery Charging Scenario 2 - Power Supply - kW
3.7
Battery Charging Scenario 2 - Percentage Change
0-100
Battery Charging Scenario 3 - Charge Time (Mins)
180
Battery Charging Scenario 3 - Power Supply - kW
11
Battery Charging Scenario 3 - Percentage Change
0-100
Battery Charging Scenario 4 - Percentage Change
N
Coupler/Connector Type
Type 2
Standard manufacturers Battery warranty - Years
8
Standard manufacturers Battery warranty - Mileage
100000
Battery Capacity in kWh
18.8
Battery Leased
0
Battery Type
Lithium-ion
WLTP - EC (kWh/100km) - Comb - TEL
18.1
WLTP - EC (kWh/100km) - Comb - TEH
20.9
WLTP - Equivalent AER (km) - Comb
78
WLTP - Equivalent AER (km) - Comb - TEL
80
WLTP - Equivalent AER (km) - Comb - TEH
65
WLTP - EC (miles/kWh) - Comb - TEH
3
WLTP - EC (miles/kWh) - Comb - TEL
3.4
WLTP - Equivalent AER (miles) - Comb
48.5
WLTP - Equivalent AER (miles) - Comb - TEH
40.4
WLTP - Equivalent AER (miles) - Comb - TEL
49.7
Charging Port Location
Left Side Front
Usable Battery Capacity
14.7
Maximum Charging Rate - kW
11
Vehicle Dimensions
Wheelbase
2865
Width (including mirrors)
2117
Height
1656
Length
4708
Width
1999
Test Cycles
Emissions Test Cycle
WLTP
RDE Certification Level
RDE 2
Engine and Drive Train
CC
1969
Cylinders
4
Cylinder Layout
IN-LINE
Number of Valves
16
Camshaft
DOHC
Fuel Delivery
TURBO DIRECT INJECTION
Catalytic Convertor
1
Engine Layout
FRONT TRANSVERSE
Transmission
SEMI-AUTO
Gears
8 SPEED
Emissions - PHEV
WLTP - CO2 Weighted (g/km) - Comb
23
WLTP - CO2 Weighted (g/km) - Comb - TEL
22
WLTP - CO2 Weighted (g/km) - Comb - TEH
32
Fuel Consumption - PHEV
WLTP - FC Weighted (l/100km) - Comb - TEL
0.9
WLTP - FC Weighted (l/100km) - Comb - TEH
1.4
WLTP - FC Weighted (mpg) - Comb - TEL
313.4
WLTP - FC Weighted (mpg) - Comb - TEH
201.5
Emissions - ICE
Standard Euro Emissions
EURO 6
Fuel Consumption - ICE
EC Directive 1999/100/EC Applies
0
General
Miscellaneous Blond headlining Natural Driftwood decor Quilted Nordico upholstery Tailored sport steering wheel. Charcoal 8-speed Geartronic™ automatic Pedals Crystal gear shift by Orrefors® Two-zone climate system Afterrun parking climate Passenger airbag cut-off switch Dual-stage airbags Knee airbag. driver side Road Sign Information Lane Keeping Aid and Lane Departure Warning Front grille with high-gloss black inserts Heated grill emblem LED headlights Trailer lamp control 12.3-inch driver display Google Assistant. Google Maps and Google Play Store Adaptive cruise control Intelligent Speed Assist (ISA) Volvo Cars App remote functions Air-ventilated subwoofer Digital Audio Broadcasting (DAB+) Harman Kardon Premium Sound Power retractable door mirrors Power passenger seat with memory Wireless phone charging Automatic door locking Remote key Door mirror covers. high-gloss black Double locking BLIS™ and Cross Traffic Alert Alarm Power child safety lock Power tailgate Keyless entry with hands-free power tailgate Air purifier and remote cabin pre-cleaning Digital owners manual Power driver seat with memory Power passenger seat Heated front seats Heated rear seats Manually foldable rear head restraints 5 seats Mechanical release second seat row Power 4-way lumbar support Textile interior cabin floor mats Protection net Rear centre armrest Illuminated vanity mirrors Interior illumination. high level Power outlet. load compartment First-aid kit Load cover. manual Auto-dimmed rear view mirrors Power cushion extension. driver Chassis Hill Start Assist Tyre pressure monitoring Oncoming Lane Mitigation Rear Collision Warning Hill Descent Control Slippery road alert Emergency brake light Heated steering wheel Adaptive power steering 19? 5-double spoke glossy black diamond cut Temporary mobility kit Lockable wheel bolts Heated windscreen Wiper blades with integrated washers Body-coloured door handles with ground lighting Tailgate scuff plate. stainless steel Volvo tread plates. aluminium High-gloss black side window trim Roof rails. glossy black Warning triangle Tempered side and rear windows Park assist. front. rear and sides Pilot Assist Electric cabin heater and cooler 360° camera Alcohol lock software (not available in the UK) Protective cap kit. Matt Tech Grey Apple CarPlay Comfort front seats 11.2-inch centre display Charging station cable. 6m Whiplash injury protection Inflatable Curtain Side impact protection Intelligent Driver Information System (IDIS) High positioned rear brake lights ISOFIX mounting points. rear seat Safety belts Rain sensor Steering wheel remote control Humidity sensor Start/Stop technology Bluetooth® connection Android Auto
